UB-GL-D29

Product:	UB-GL-D29
Classification:	LED Garden Light
Port:	Shanghai, China

Product Specifications

Light Source	30 ~ 150 Watts Optional
LED Chip	150 ~ 170 lm / W, Service life of more than 50,000 hours
LED Chip Brand	Cree, Lumileds, BridgeLux, Epistar etc Optional
Luminous Flux	4500 ~ 25500 lm
CRI	> 70 Ra
Power Factor	＞ 0.95
Color Temperature	3000 K ~ 6000 K Optional
Beam Angle	80° * 145° / 90° * 90° / 120° * 120° Optional
Input Voltage Rage	90 ~ 305 V, 50 / 60 HZ
Lightning Protection Level	10 KV
LED Driver	MeanWell, PHILIPS, Inventronics, MOSO, SOSEN etc Optional, IP 67
Lamp Shell Material	Pressure Die Casting Aluminum with Powder Coating
Installation Diameter	Φ 60 mm
IP Rating	IP 66
IK Rating	IK 09
Working Temperature	- 45℃ ~ + 60℃
Working Humidity	10% ~ 90%
Product Size	Φ 480 * H 525 mm
Package Size	590 * 510 * 165 mm
Net Weight	11.2 KG
Gross Weight	12.5 KG
Number of Packing	1 Pcs / Carton
Warranty	5 Years

Features

■ Using precision die-cast aluminum ADC12 material, the structure of die-casting manufacturing process is stable.

■ The surface is hot-dip galvanized and sprayed, which has strong corrosion resistance and adapts to harsh and complicated environments.

■ The installation fixing hole is designed according to the installation method of the street lamp, and the construction and installation are convenient.

■ The heat dissipation design of the power supply compartment and the heat sink effectively extends the lifetime of LED chips.

■ Multi-beam angles, 90° / 120° / 145 * 80°, for options, which is suitable for different application scenarios.

■ Special olivary design, matching with the surrounding.

■ Regular, timing, 0-10V and DALI dimming control methods for options; Meanwhile, photocell can be equipped, according to different applications.

Certificates

Application Areas

LED Garden Lights is widely used in public areas and residential areas as follows

▲ Road and Street

▲ Office Buildings

▲ Gardens, Parks

▲ Residential areas like villa and appartment or houses

FAQ

1. Can I have a sample order for led light ?

Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

2. What about the lead time ?

Sample needs 3 - 5 days, mass production time needs 1 - 2 weeks for order quantity.

3. Do you have any MOQ limit for solar lighting product order ?

No, even only buy 1 set as a sample for test is also available.

4. For sample, how do you ship the goods and how long does it take to arrive ?

We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3 - 5 days to arrive. Airline and sea shipping also optional.

5. Is it OK to print my logo on led light product ?

Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

6. What's your warranty ?

We provide 5 years warranty for the whole set lighting system, replace any damaged parts free of charge during the warranty period. but the product damage caused by force majeure is excepted.
